Description

Key Features of the DR6000 Series Refractometers

• Very fast and reliable measurement
• Measurement of turbid and highly viscous samples
• Four different models available depending on accuracy needs and measurement range requirements
• Ranges include nD 1.32000 to nD 1.70000 +/- 0.00001; 0-95% Brix / User-defined scales are also available
• Fast and accurate Peltier temperature control (10 to 80°C) or Temperature Compensation (ICUMSA or freely definable)
• Chemically resistant materials such as sapphire prism
• Intuitive operation via touchscreen display
• Complete data recording and backup including audit trail
• User authorization levels
• Conforms with National and International standards such as 21 CFR Part 11, GMP/GLP, ICUMSA, ASTM, ISO, AOAC International, USP, BP, JP, Ph. Eur, OIML, ISO, DIN, OIV, AOCS and more

Abbe Refractometers:

Abbe refractometers measure the refractive index based on the principle of the total reflection that occurs at the boundary between a prism and a sample. They are ideal for the measurement of the refractive index of solid samples such as glass, plastics, polymers as well as foils, pastes and viscous liquids. A.Krüss Optronic carries two Abbe Refractometer models.

• Determine refractive index between nD 1.3000 and 1.7200 and the sugar content in the range of 0 – 95 % Brix
• Scales are adjusted manually using the drive knob and the measured value is read through the eyepiece
• Integrated digital thermometer shows temperature on the LCD display
• Temperature control is available via an external circulating water bath (not included) such as the Krüss PT31 or PT80

• Digital LCD display of refractive index or Brix value together with the temperature
• Automatic temperature compensation feature
• Measurement range of 1.3000 to 1.7200 nD; 0 to 95% Brix
• Designed for harsh environments
• Thermostat connections for both illumination prism and measurement prism
• Serial RS-232 and RS-422 interfaces
• Temperature control is available via an external circulating water bath (not included) such as the Krüss PT31 or PT80

Process Refractometers:

Accurate Results for Automatic and Continuous Process Control

A.Krüss Optronic offers both “In-Line” and “At-Line” for monitoring refractive index in a process environment:

For Features, Specifications  and Applications for these Process Refractometer models see the links below or contact your AGS Sales representative:

Inline Refractometer Information

Atline Refractometer Information

Digital Handheld Refractometers:

A.KRÜSS Optronic Digital hand-held refractometers are ideal for mobile use and have a large measurement range. Use them to inspect incoming goods, optimize quality assurance and reduce work processes. They are lightweight and easily fit in a lab coat pocket. There are three models to choose from:

DR301-95 Key features:

• The most advanced digital hand-held model with many features and functions found in the standard laboratory model
• Large measuring range and high precision: nD 1.3330 to 1.5318, 0-95% Brix
• Choose from refractive index scale, sugar scale, salt scale plus the ability for programming 2 User-defined scales
• Use the 9-volt battery option for mobility or the optional power supply to convert it into a small laboratory unit
• Easy to calibrate with water
• Temperature compensation for Brix measurements from 5 to 40 degrees C
• Robust casing, light weight and easy to clean
• USB Interface allows for sending data to PC or printer
• Alarm option for monitoring limit values in production

DR201-95 Key Features

• Compact digital hand-held refractometer which eliminates errors caused by misreading a manual refractometer
• Wide measuring range on the refractive index scale (1.3330 to 1.5318 nD) and the sugar scale (0 to 95% Brix)
• Splash proof and meets IP64 Standard
• Easy to calibrate with water
• Rugged case and low maintenance
• Temperature compensation from 10 to 40 degrees C for measuring sugars in beverages and confectionaries
• 5 V battery lasts for over 1000 measurements

DR101-60 Key Features

• Good entry-level model with measurement range of 1.3330 to 1.4419 nD, 0 TO 60% Brix
• Low cost and low maintenance
• Waterproof case allows the unit to be rinsed under running water and meets IP65 Code
• Temperature compensation from 10 to 40 degrees C for Brix measurements
• Easy to calibrate with water

Click the following link for more information Digital Handheld Refractometer Information

Handheld Refractometers:

Handheld refractometers are barely larger than a flashlight and can be used just about anywhere. They are easy to use, very robust and require no batteries. The models will differ based on their application such as the determination of salt content (salinity), water content in honey, Brix, alcohol content, urine and serum specific gravity, Oechsle, antifreeze and battery acid.

Key Features:

• Small size for mobile use
• Automatic temperature compensation for all models
• High resolution of the scale areas
• Robust and compact design
• Easy calibration and adjustment
